When a Singapore MEP consultancy writes a specification for an Indonesian data centre, two standards frameworks collide on the same cable tray schedule: the US-origin NEMA VE 1 (which most hyperscale DC template specs carry by default) and the Indonesian National Standard (SNI) family that BPJT and government procurements require domestically. Understanding where these overlap and where they diverge is not academic — it determines whether a submitted submittal package gets approved or returned.
This post maps both standards side by side across load classification, test methods, corrosion requirements, and marking, identifies the precise divergence points, and shows how dual-certified product resolves the compliance gap without requiring in-room equivalence arguments at submittal review.
What Each Standard Covers
NEMA VE 1 (Metal Cable Trays — Mechanical Loading) is published by the National Electrical Manufacturers Association. It defines load classes, dimensional tolerances, test methods, and marking requirements for metallic cable tray systems used in industrial, commercial, and data centre environments. The current edition is VE 1-2017. It is the reference standard on most US-authored design basis documents and hyperscale DC global template specifications.
SNI for cable tray in Indonesia falls under SNI IEC 61537:2016 (Cable tray systems and cable ladder systems for cable management), which is Indonesia’s adoption of the IEC 61537 standard. Government projects under Perpres 16/2018 procurement rules require SNI-certified product; TKDN incentive structures further reinforce domestic SNI compliance. For a detailed Indonesian-language reference on SNI cable tray standards, see the SNI authority post.
The practical question for most cross-border projects is: do these two frameworks require different products, or does a tray certified to one automatically satisfy the other?
Standards Comparison Table
| Criterion | NEMA VE 1-2017 | SNI IEC 61537:2016 |
|---|---|---|
| Scope | Metallic cable tray systems; ladder, ventilated trough, solid bottom, channel types | Cable tray systems and cable ladder systems; metallic and non-metallic |
| Load classification | Classes 5A, 8A, 12A, 16A, 20A (max uniform distributed load in lbf/ft; suffix A/B/C indicates rated test span) | Classes A, B, C, D defined by maximum uniform distributed load (UDL) over rated span; load increases progressively from A (lightest) to D (heaviest) |
| Load test — uniform distributed | Section 5.4: UDL over rated span; max deflection L/100 | Section 8.4: UDL over rated span; max deflection L/100 |
| Load test — point load | Section 5.5: concentrated load at centre span | Section 8.5: 1,000 N point load at mid-span (Classes B–D) |
| Deflection limit | L/100 under UDL; permanent set ≤ 0.25 in | L/100 under UDL; no permanent set after test cycle |
| Corrosion / coating | Section 6: HDG per ASTM A123/A153; pre-galvanised per ASTM A653; stainless 304/316 | Annex B: HDG per ISO 1461; pre-galvanised per ISO 3575; neutral salt spray per ISO 9227 |
| Electrical bonding test | Section 7: 50 A test current; resistance ≤ 0.1 Ω per joint | Clause 9.5: 25 A AC test; resistance ≤ 0.1 Ω per joint |
| Marking | Section 8: manufacturer name, load class, span rating, catalogue number, production code | Clause 10: manufacturer name, load class, batch reference, SNI mark (mandatory for government projects) |
| Certification body | UL listing or NRTL third-party test lab | Sucofindo / BSN-accredited lab; SNI mark mandatory for regulated procurement |
Where the Standards Align
The structural engineering logic underlying both standards is the same. Both use L/100 deflection as the governing serviceability criterion under uniform distributed load. A NEMA 8B-rated perforated tray maps closely to IEC Class B on structural performance at equivalent spans. Dimensional tolerances for width, depth, and section modulus targets are compatible. A tray section that passes NEMA VE 1 load testing will, in most configurations, pass SNI IEC 61537 load testing on structural performance. This alignment at the physics level is why the perceived incompatibility between NEMA-spec’d and SNI-governed projects is mostly a documentation and certification problem rather than a product performance one.
Where They Diverge
1. Corrosion classification methodology. NEMA VE 1 references ASTM standards; SNI IEC 61537 references ISO equivalents. For hot-dip galvanising, ASTM A123 and ISO 1461 target nearly identical zinc mass — the outputs are equivalent. But a spec citing one standard cannot simply reference the other’s test report: the Certificate of Conformity must cite the applicable test standard. Submit the right certificate for the right framework.
2. Electrical bonding test current. NEMA specifies 50 A; IEC/SNI specifies 25 A. A tray passing the NEMA 50 A test exceeds the SNI 25 A requirement — this is not a product gap. It is a documentation gap: if a government inspector requests the SNI 25 A test record and you present a NEMA 50 A record, you need to make the equivalence explicit in writing.
3. SNI mark requirement. Indonesian government procurements require the physical SNI mark on the product. A NEMA listing or UL cert does not substitute for it. This is a certification-body requirement, not a performance gap — the same tray must go through an accredited Indonesian inspection body (e.g., Sucofindo) to carry the mark.
Adjacent Standards: BS EN 61537 and IEC 61537
Projects with UK-trained lead consultants — common in Singapore and on legacy ASEAN infrastructure — frequently cite BS EN 61537. BS EN 61537 is the British adoption of IEC 61537. SNI IEC 61537:2016 is Indonesia’s adoption of the same base document. A product tested and certified to IEC 61537 satisfies BS EN 61537 and SNI IEC 61537:2016 simultaneously for core technical requirements — though each market may require its own certification mark.
Specifiers on projects where both UK and Indonesian procurement teams review submittals should note this explicitly in the compliance matrix. Stating “product is certified to IEC 61537; BS EN 61537 and SNI IEC 61537:2016 are national adoptions of the same base standard” pre-empts a duplicate submittal review cycle.
Dual-Certified Product: The Practical Resolution
A cable tray that holds both NEMA VE 1 test records and a current SNI certification (issued by an accredited Indonesian inspection body) can be specified under either framework without equivalence arguments. The submittal package presents the applicable certificate for whichever regime governs.
PT Metalindo Tosan Surya (METOSU) perforated and ladder cable trays carry Sucofindo certification reports E26933/FNBPAS (perforated tray, NEMA Class 8B, working load 300 kg/span, ultimate 420 kg/span at 2,400 mm) and E26929/FNBPAS (cable ladder, NEMA Class 8C, working load 500 kg/span, ultimate 1,340 kg/span at 2,400 mm), covering load classification, corrosion resistance, and earthing continuity per SNI IEC 61537:2016. These are available directly from METOSU’s certification pack on request.
Need certification copies for your project? Get them direct.
Full product range: Cable Tray | Cable Ladder
Worked Spec Examples
Example 1: Hyperscale DC — NEMA-Anchored Spec with Domestic SNI Override
A hyperscale operator’s global design basis document specifies:
“Cable tray systems shall comply with NEMA VE 1-2017, Class 8B, hot-dip galvanised per ASTM A123.”
The Indonesian subsidiary’s local procurement policy adds:
“All products shall carry a valid SNI certification mark per applicable SNI standards.”
Compliance path: Specify METOSU perforated cable tray, NEMA Class 8B per Sucofindo report E26933/FNBPAS (working load 300 kg/span, ultimate 420 kg/2,400 mm span), HDG per ISO 1461 (equivalent to ASTM A123 for zinc mass) with SNI IEC 61537:2016 certification. The submittal covers both requirements. The compliance matrix should note: NEMA 8B ↔ IEC Class B; ASTM A123 ↔ ISO 1461; SNI certification satisfies the domestic overlay requirement.
See also: Data Centre applications.
Example 2: Indonesian Government Project — SNI-Anchored Spec with International Equivalent Clause
A government infrastructure project specifies:
“Kabel tray harus memenuhi SNI IEC 61537:2016, Kelas C. Setara internasional diperbolehkan dengan persetujuan Direksi Pekerjaan.”
Compliance path: METOSU’s SNI-certified product (Sucofindo E26933/FNBPAS) is the primary qualifying document — no equivalence argument required. If the procurement committee requests international benchmarking, the same product’s IEC 61537 load and bonding test data is the applicable reference, since SNI IEC 61537:2016 is IEC 61537 adopted as Indonesian national standard. The “international equivalent” approval step is pre-satisfied.
Common Procurement Pitfalls
Accepting a “compliant” claim without the test report. A vendor datasheet that says “complies with NEMA VE 1 and SNI” is a marketing statement. The certification is the Sucofindo report number or the NRTL listing certificate, referencing the specific test method and result. Always request the actual test report.
Confusing batch certification with product-line certification. Some certifications cover a specific production batch tested at a point in time; others cover an ongoing manufacturing process with periodic re-audit. Ask whether the certificate applies to all product dispatched today or only to the tested batch. Verify the scope of product codes on the certificate.
Missing the physical SNI mark on government projects. For government projects governed by mandatory SNI product standards, the physical tray must carry the SNI mark — embossed, stamped, or labelled per the applicable regulation. A paper certificate does not substitute for the physical mark. Verify that the manufacturer’s production line applies the mark, not merely that they hold the certificate.
Not aligning the corrosion environment to the corrosion class. Both standards provide corrosion environment guidance in different frameworks (NEMA environmental types vs. IEC 60721-3 classification). For coastal Indonesian installations or rooftop cable paths, standard HDG may be insufficient — a duplex system (hot-dip galvanising under a Jotun powder topcoat) is the appropriate upgrade. Corrosion class selection should be explicit in the spec — do not leave it to the product default.
Summary
NEMA VE 1 and SNI IEC 61537 are structurally compatible standards that diverge at three specific points: corrosion test reference standards, electrical bonding test current, and certification mark requirements. For most load classes used in commercial and data centre cable management, a tray that passes one framework’s structural tests will pass the other’s — the compliance gap is documentation and certification body, not product performance.
For cross-border projects where both frameworks appear in the same spec, dual-certified product with both NEMA test records and SNI certification marks eliminates the compliance gap without equivalence arguments at submittal. The worked examples above illustrate the path for the two most common project archetypes in the Indonesian market.
